PCB design is a complex combination of art and science.
The most artfully crafted design is nothing unless the circuit works.
Our designers are well versed in the science of EMI, crosstalk, reflections, bypass and decoupling methodologies, minimizing inductance and minimizing loop area, and complex fan-out methods.
We create beautiful art that works the first time. An additional benefit; designs are typically done in much less time than in-house design teams since our talent is strictly focused on fast, high quality design, nothing else.
Features- IPC certified interconnect designers (CID)
- A complete design and assembly service
- Symbol and component
- Schematic
- PCB
- Assembly
- Documentation
- Revisions
- Conversions
- Reverse Engineering
- Schematic (Concept, Orcad, PADS Logic, DX Designer)
- PCB (Allegro, PADS Layout, PADS Router)
- Gerber Files, NC-Drill File, IPC Netlist
- Fabrication Drawing (PDF and/or DXF)
- Assembly Drawing (PDF and/or DXF)
- Pick and Place File (Component Location Coordinates)
- Differential Pairs and Matched Length Traces
- Controlled Impedance
- IPC Standards
