PB–Series Portable Absolute and Gauge Pressure Transducer
Brand: Alicat ScientificPB-Series Portable Absolute and Gauge Pressure Transducers measure absolute or gauge pressure anywhere you need for all non-corrosive gases, making them ideal for on-the-go process calibration, verification, and validation.
Features- User changeable units of measurement: Change the unit of pressure measurement from our extensive list of engineering units
- Monochrome backlit LCD with integrated touchpad: Easily read measurements using the backlit display and control configurations with the user-friendly integrated touchpad
- Communication protocols: Serial over micro-USB; Bluetooth for use with Alicat Connect app
- Displays: Backlit monochrome or color
- Process connections: NPT, SAE, AN, BSPP/G, compression, VCR, or VCO fittings
- Elastomers: Viton, FFKM, EPDM, Silicone
- Calibration: High-accuracy; custom calibration points
Specifications
Brand
Full Scale Range
- Absolute: 0-15 psia to 0-3,000 psia
- Gauge: 0-2 inH₂O to 0-3,000 psig
Measurement Range
- 0.01 % to 100 % of Full Scale Pressure
Calibration Accuracy
- Standard NIST-Traceable: ± 0.25 % of Full Scale
Repeatability
- 0.08 % of Full Scale
Response Time
- Typical < 10 millisecond
Warm-Up Time
- < 1 s
Compatible Gases
- All Non-corrosive Gases
Operating Temperature
- -10° to +60° C
Burst Pressure
- 3x Full Scale (1.5x Full Scale for Ranges > 500 psi)
Accuracy
- High Accuracy: ± 0.125 % of Full Scale
- Analog Signal: ± 0.1 % of Full Scale Additional Uncertainty
Wetted Material
- 302, 303, and 304 Stainless Steel
- FKM
- Alumina Ceramic
- Glass
- Gold
- Heat-cured Epoxy
- Heat-cured Silicone Rubber
- Polyamide
- Silicon
Process Connection
- 1/8″ NPT Female
Communication
- RS-485 Serial
- Modbus RTU (Over RS-232 or RS-485 Serial)
- Modbus TCP/IP
- DeviceNet
- EtherCAT
- EtherNet/IP
- Serial Over Micro-USB
Power Requirement
- 5 Vdc, 1 A Recommended Via An Outlet Adapter to USB
- 9-28 Vdc, 40 mA
- 12-28 Vdc, 40 mA
- 12-28 Vdc, 80 mA
