Approvals & Certifications
Flow Accuracy
- Standard: ±2% Full Scale, Class 2.5 acc VDI/VDE
- Optional: ±1% Full Scale, Class 1.6 acc VDI/VDE
Ambient Temperature
- 33° to 125° F (1° to 52° C)
Connection
- Female NPT/150# Flange - Vertical or Horizontal
Material of Construction
- Metering Tube: Borosilicate Glass
- Protective Tube Sleeve: UV Stabilized Polycarbonate
- Window: Scratch Resistant, UV Stabilized Polycarbonate
- Floats & Float Stops: Glass, Sapphire, 316 Stainless Steel or Carboloy / Teflon
- End Fitting: Brass or 316 Stainless Steel
O-rings/Packing Material
- Buna-N, Viton®-A Fluoroelastomers, Kalrez® 4079 Perfluoroelastomers (Sizes 8-10)
- Neoprene, Viton® or Teflon® Packing (Sizes 2,6)
